Image preview - the first page of the document
63892-WW-1


>> Download 63892-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Modification of Fix Rod
                                                                                                   63892


For Models            HR4000C, HR4040C
Country               All countries
Description           Fix Rod has been modified for quick repair as shown below.

                        Motor Housing Complete


                                        Controller
                                                                     Current                   New




                                 Fix Rod




                                                                                   This portion has been added
                                                                                      to hold the controller.




Interchangeability(I/C)
  Item No.       Current part                    Q'ty I/C         New part           Q'ty         Note
HR4000C: 105 Fix Rod                                         Fix Rod
                                                     1                                1
HR4040C: 107 415695-0                                        417715-6

Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
HR4000C: From serial No. 163689E (May, 2001)
HR4040C: From serial No. 3069E (July, 2001)
