Image preview - the first page of the document
63896-WW-1


>> Download 63896-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject             Addition of Cover
                                                                                                   63896


For Models           GV7000, GV7000C, PV7000C, PV7001, PV7001C

Country              All countries
                     A cover has been added beside the Grip to prevent cooling air from blowing
Description
                     out directly toward a hand.
                     The Cover and the Grip are installable on both right and left sides.




                           Cover
                         (417793-6)




                                                 Grip
Interchangeability(I/C)
Item No.      Current part                 Q'ty I/C            New part                     Q'ty   Note
  See                                                   Cover
                                                                                             1
 below                                                  417793-6

Note
  Model GV7000 GV7000C PV7000C PV7001 PV7001C
Item No. 041     041     043    047     047

Implementation
GV7000: To be informed later.
GV7000C: From serial No. 1540E (May, 2001)
PV7000C: From serial No. 1482E (May, 2001)
PV7001: From serial No. 1004E (June, 2001)
PV7001C: From serial No. 1042E (May, 2001)
