Image preview - the first page of the document
63825-WW-1


>> Download 63825-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Pin 4 and Sleeve
                                                                                                               63825


For Models            6827

Country               All countries

Description           See below.


            sleeve                                                                   New
                                         Pin 4            The diameter of each Pin 4 is
                                                          very slightly enlarged.




                                                                                          Each through hole for Pin 4
              Pin 4                                                                       is also very slightly enlarged.


Interchangeability(I/C)
Item No.       Current part              Q'ty I/C            New part                      Q'ty             Note
   055   Pin 4                                        Pin 4
                                           2                                                 2    See below for detailed
   056   256226-4                                     268075-7
                                                                                                  information of
         Sleeve                            1          Sleeve                                 1    interchangeabiliy.
   060
         324141-1                                     324209-3
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.
 The arrow      means that the current part can be substituted for the new.
Combinations of the Two Parts and Interchangeability
Which combination can be used for repairing?

                                                 Sleeve
                                  the current one        the new one
                                (Part No.324141-1)    (Part No.324209-3)
            the current one
          (Part No.256226-4)           Yes                    Yes
 Pin 4
             the new one
          (Part No.268075-7)
                                       No                     Yes


Implementation
 From Apr. 2001
