Image preview - the first page of the document
63975-WW-1


>> Download 63975-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Pan Head Screw M5x18
                                                                                                        63975


For Models            9060L, 9067, 9067L, 9067S, 9069, 9069S, 9617, 9617L

Country               All countries

Description           4 pcs. of Pan Head Screw M5x18 without adhesive have been replaced by ones with adhesive.

                       Current                                                     New



                                           Gear Housing                                            Gear Housing
                                           Complete                                                Complete


                                       Bearing Box                                              Bearing Box

                         Pan Head Screw M5x18                                    Pan Head Screw M5x18
                         without adhesive: 4 pcs.                                with adhesive: 4 pcs.
                                                                                 (The color of adhesive is orange.)



Interchangeability(I/C)
Item No.      Current part                  Q'ty I/C           New part                  Q'ty         Note
See note Pan Head Screw M5x18                 4         Pan Head Screw M5x18              4
below.   911226-8                                       911230-7

Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.


Note
Item No. for Pan Head Screw M5 x18
No.013: 9617L, 9617
No.030: 9060L
No.034: 9067, 9067L, 9067S, 9069, 9069S


Implementation
Machines manufactured in MJ (Makita Japan)
9060L: From your next order
9067 : From serial No. 31019E (Jun., 2001)
9067L: From serial No. 60291E (Jun., 2001)
9069 : From serial No. 113188E (Jun., 2001)
9617 : From your next order
9617L: Discontinued since Oct., 2000

Machines manufactured in MCC (Makita (China) Co., Ltd.)
9060L, 9067, 9067L, 9067S, 9069, 9069S: To be informed later
