63986-WW-1


>> Download 63986-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Flat Washer 8
                                                                                                             63986


For Models             4157KB, 5057KB

Country                All countries

Description            For smoother operation of Lever Plate, the thickness of Flat Washer 8 has been changed from
                       3 mm (1/8") to 4 mm (5/32").

                       Current                                                        New
                   Flat Washer 8           Lever Plate                        Flat washer 8        Lever Plate
                   ( 3mm thick)                                               ( 4mm thick)

     Lever Plate                                                Lever Plate




                                            Angular Plate                                             Angular Plate

                                       Depth Guide                                             Depth Guide



Interchangeability(I/C)
Item No.     Current part                  Q'ty I/C              New part               Q'ty            Note
   030 Flat Washer 8                                     Flat Washer 8
                                            2                                            2
   060 267003-9                                          253766-3

Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.


Implementation
To be informed later
