Image preview - the first page of the document

>> Download 64040-WW-1 documenatation <<

Text preview - extract from the document
Subject               Change of Center Cover in Shape

For Models            LS1013
Country               All countries except for U.S.A., Canada, Mexico, Panama, Chile and Brazil
Description            Center cover has been changed in shape to make motion of safety cover smoother as shown below.

                             Center Cover

                                                                               Current                      New

                                                                        Two protrusions                No protrusions

 Item No.         Current part                  Q'ty I/C           New part                       Q'ty         Note
             Center Cover                                  Center Cover
    077                                          1                                                 1
             344380-7                                      345226-0

 Interchangeability mark ;
  The arrow      means that the new part can be substituted for the current.

This change is not applied to LS1013 manufactured by MCA (Makita Corporation of America) for U.S.A., Canada,
Mexico, Panama, Chile and Brazil.

LS1013: From serial No. 111133E(June, 2001)
