TECHNICAL INFORMATION
Subject               Change of Hex. Socket Head Bolt M4X16
                                                                                                      64056

                      9560, 9560C, 9560CV, 9561, 9561C, 9561CV, 9562, 9562C, 9562CV, 9563, 9563C, 9563CV,
For Models            9564, 9564C, 9564CV, 9564CVL, 9565, 965C, 9565CV, 9565CVL
Country               All countries
Description           Hex. Socket Head Bolt M4X16 has been changed as shown below.




                                                        Current                            New




                                                                                                 Adhesive
                                                                                              (color: Orange)

                                            Hex. Socket Head Bolt M4X16        Hex. Socket Head Bolt M4X16
                                                (with Spring Washer)              (with adhesive applied)
                                                     (266260-6)                         (265490-6)




Interchangeability(I/C)
Item No.          Current part                    Q'ty I/C             New part                Q'ty     Note
           Hex. Socket Head Bolt M4X16                       Hex. Socket Head Bolt M4X16
    052                                             4        265490-6                            4
           266260-6
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

 Implementation
9565C: From serial No. 7972E (June, 2001)
9565CV: From serial No. 17324E (June, 2001)
The remaining models: To be informed later.
