Image preview - the first page of the document
64010-WW-1


>> Download 64010-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Helical Gear 43 Complete and Helical Gear 12
                                                                                                                64010


For Models             9403, 9921
Country                All countries

Description            Helical Gears in subject have been modified in order to increase their durabilities. To distinguish
                       the new items from the current ones, see the information as below.

                           Current                                                          New
                                                                          Induction Hardening has been added in
                                                                                its manufacturing process.




                                            Color: Silver                                           Color: Black

                 Helical Gear 43 Complete                                       Helical Gear 43 Complete
                        (153265-4)                                                     (153291-3)

                                                                            It has been replaced by harder one.




                                         No groove                                                      A groove
                       Helical Gear 12                                               Helical Gear 12
                        (226506-2)                                                    (226551-7)


Interchangeability(I/C)

Item No.        Current part                      Q'ty I/C             New part                        Q'ty       Note
           Helical Gear 43 Complete                           Helical Gear 43 Complete
    041                                              1   No                                             1
           153265-4                                           153291-3                                        Interchangeable
           Helical Gear 12                                    Helical Gear 12                                      as a set
    064                                              1   No                                             1
           226506-2                                           226551-7

Implementation
To be informed later
