Image preview - the first page of the document
6402-TE


>> Download 6402-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.             6402
                                                                                                           New Tool


    Description             MAKITA 10 mm Drill

CONCEPTION AND MAIN APPLICATIONS
   This machine is the more high-graded model
   of the 6510LVR.                                                                  264
   By holding the motor in some between this                                        70
   model and the 6820V, the power has been
   upgraded. For the drill chuck, the outer




                                                                                                     178
   diameter has been enlarged than that of 6510LVR
   to increase the gripping force and to make
   the high grade feeling.



  Specifications
                                                           Consumed            Rated
     Voltage(V)       Current(A)       Frequency(Hz)                                         Max. output(W)
                                                           power(W)          output(W)
         100               6.0              50-60             570               280                460
         115               5.2              50-60             570               280                460
         200               3.0              50-60             570               280                460
         220               2.7              50-60             570               280                460
         230               2.6              50-60             570               280                460
         240               2.5              50-60             570               280                460

    No load speed(R.P.M.)                                0-1,200rpm
    Chuck capacity(mm)                                   0.6-10mm
    Capacity(mm)                      for steel          10mm
                                      for wood           21mm
    Net weight(kg)                                       1.7kg
    Cord length(m)                                       2.5m


  Standard equipment
   Chuck key 10


  Features and benefits
   1. With the powerful motor(6510LVR:330W) of 570W, the high working efficiency can be achieved without
      stressing the motor.
   2. Low noise provides the comfortable operation.
   3. With the non-step variable speed switch, positioning for drilling can be easily done.
   4. The built-in reversing change function enables the drill to be easily detached.
   5. The gripping force has been increased with the large outer diameter "43" (6510LVR :38) of the large model
      drill chuck.




   The standard equipment for the tools shown may differ form country to country.
Circuit    drawing
 a. Domestic & general specifications
 * The terminal board is used for export to America.
                                                                           Violet


                                     5 6                                   White
                                                     Terminal board
                                     3     4

                                     1 2
                            Reversing change switch
                                                                      Orange
                                                                      color
            Cab tire cord




                                   Main
                                                                           Black                     Auto winding field
                                  switch

                                                     Capasitor



 b. For the countries where the interference protection is required (for West Germany, Austria, France, Holland, England etc.)


                                                                      Yellow                                    Auto winding field
                                     5 6
                                                                      Black
                                    3      4

                                     1 2                          Orange
                                                                  color
                              Reversing change
                              switch
           Cab tire cord




                                                                      White
                                  Main
                                                                      Black
                                  switch
                                                                      Violet


                                               Capasitor





 1. Connect the reversing change switch as shown
    on the right figure. Although the terminal numbers
    are not displayed, they are specified as shown on                                                         (6)
    the figure for the convenience.                                            Normal turn                      (5)
                                                                                                                (3)
                                                                                                                (1)
                                                                               Reverse turn




                                                                                              Motor housing


 2. Depending on the destinations, the condenser is not used or the three legs are used in some areas.
