TECHNICAL INFORMATION
Subject                Modification of Spindle and Change from Flat Washer 24 to Cup Washer 14
                                                                                                           64034


For Models             6916D, 6918D, 6990D, 6991D, 6992D, BTD120, BTW120, BTW121
Country                All countries
Description            Spindle has been modified and Flat Washer 24 has been replaced by
                       Cup Washer 14 as shown below.


                        Current                                                        New
             Stepped                                                        No step




       Spindle                         Flat Washer 24               Spindle                  Cup Washer 14
     (323994-5)                          (267175-0)               (324220-5)                   (267766-7)



Interchangeability(I/C)
          Item No.                       Current part          Q'ty I/C     New part             Q'ty        Note
6916D, 6918D: 027                      Spindle                       Spindle
                                                                1 No                              1
6990D, 6991D, 6992D: 030               323994-5                      324220-5
BTD120, BTW120, BTW121: 027                                                                             Interchangeable
6916D, 6918D: 026                      Flat Washer 24                Cup Washer 14                           as a set
                                                                1 No                              1
6990D, 6991D, 6992D: 014               267175-0                      267766-7
BTD120, BTW120, BTW121: 026


Implementation
6916D: From serial No. 8349E (July, 2001)
6918D: From serial No. 10852E (July, 2001)
6990D: From serial No. 4563E (July, 2001)
6991D: From serial No. 1734E (July, 2001)
The remaining Models: To be informed later.
