Image preview - the first page of the document
64194-WW-1


>> Download 64194-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Endbell Complete
                                                                                                            64194


For Models              BTW150, BTW151
Country                 All countries

Description             Endbell Complete has been changed for a quick repair as shown below.
                        The new Endbell Complete can be distinguished from the current one by color of Rubber Pin.


                           Current                                                   New
                                                                                                Rubber Pin (green)
Rubber Cap 12                                                                             It is longer by 1 mm than the
 (421790-6)             Washer          Rubber Pin (blue) Rubber Cap 12                    current Rubber Pin (blue).
                                                                        Washer has been eliminated.




                                             Spacer                                                    No Spacer




                  Endbell Complete                                              Endbell Complete
                (638088-6 / BTW150)                                           (638115-9 / BTW150)
                (638073-9 / BTW151)                                           (638116-7 / BTW151)
    Washer, Rubber Pins(4pcs.) and Spacers(4pcs.) are              Rubber Pins(4pcs.) are the constituent parts
    the constituent parts of current Endbell Complete.             of new Endbell Complete.


Interchangeability(I/C)
Item No.       Current part                    Q'ty I/C         New part                        Q'ty       Note
           Endbell Complete                               Endbell Complete
    038                                         1                                                1     For BTW150
           638088-6                                       638115-9
           Endbell Complete                               Endbell Complete
    038                                         1                                                1     For BTW151
           638073-9                                       638116-7
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.
 Note
Washer and Spacers(4pcs.) have been eliminated in the new Endbell Complete.

Implementation
To be informed later.
