Image preview - the first page of the document
64199-WW-1


>> Download 64199-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject
                                                                                                        64199
                                                                                                  (page 1 of 2)
                       Change of Gear Housing Complete, Gasket, Gear Housing Cover Complete and Addition of Pin 3
For Models             GV7000, GV7000C, PV7000C, PV7001, PV7001C
Country                All countries
Description            Regarding models PV7000C, PV7001, and PV7001C, Gear Housing Complete, Gasket and
                       Gear Housing Cover Complete have been changed, and Pin 3 has been added as shown below.
                       Regarding GV7000 and GV7000C, only Gasket has been changed.


                                                                        Pin 3 has been added to Model PV7000C,
                                                                        PV7001 and PV7001C only.
                                                                        (No addition of Pin 3 to GV7000 or GV7000C)


                 Gear Housing Complete

                                       Gasket
                                                    Pin 3
                                                 (256157-7)

                                         Gear Housing Cover Complete




 Gear Housing Complete

                        Current                                                     New




          (152691-4)                                                (153318-9)      A hole for Pin 3 has been added.

 Gasket
                        Current                                                     New



                                                                                                    A hole for Pin 3
                                                                                                    has been added.
                       (442132-1)                                                (417837-2)

 Gear Housing Cover Complete

                        Current                                                     New


                                                                                                    A hole for Pin 3
                                                                                                    has been added.

    (152692-2)                                             (153319-7)
                                                                                                    64199
                                                                                                  (page 2 of 2)

 Interchangeability(I/C)
  PV7000C, PV7001, PV7001C
        Item No.             Current part               Q'ty I/C          New part         Q'ty     Note
                        Gear Housing Complete                      Gear Housing Complete
          005                                             1                                 1
                        152691-4                                   153318-9
                        Gear Housing                               Gear Housing
          013           Cover Complete                    1        Cover Complete           1
                        152692-2                                   153319-7
PV7000C: 044                                                       Pin 3                    1
PV7001, PV7001C: 048                                               256157-7
                        Gasket                                     Gasket
          012                                             1                                 1
                        442132-1                                   417837-2

  GV7000, GV7000C
 Item No.     Current part                       Q'ty I/C            New part              Q'ty     Note
           Gasket                                             Gasket
    012                                            1    Yes                                 1
           442132-1                                           417837-2

 Interchangeability mark ;
  The arrow      means that the new part can be substituted for the current.

 Note
Regarding GV7000 and GV7000C, Gear Housing Complete and Gear Housing Cover Complete remain unchanged.

 Implementation
GV7000C: From serial No. 1798E (July, 2001)
The remaining models: To be informed later.
