Image preview - the first page of the document
6410-TE


>> Download 6410-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
     Models No.                  6410                                                       248mm(9- 3/8")
                                                                                                              New Tool


     Description                 10mm Drills




                                                                                                                 183mm(7- 3/16")
  CONCEPT AND MAIN APPLICATIONS
  Model 6409/6410 are redesigned versions of the existing 10mm
  drills and their brief benefits are;
     *Reasonable price                                                           63mm(2 -1/2" )
     *Easy operation
        by ergonomic design for easily pushing the axis of drilling
                                                                                             250mm(9 -7/8")
                                 Reversing
   Model       Speed control     direction       Drill chuck




                                                                                                                        183mm(7- 3/16")
                                 of rotation
                                                Conventional
    6409           No               No            (Keyed)
    6410           Yes              Yes           Keyless

                                                                                  63mm(2- 1/2" )

      Specifications
                                                                Continuous Rating (W)                Max.
     Voltage (V)      Current (A)         Cycle (Hz)
                                                               Input         Output                Output(W)
         100               3.7                 50/60            350             170                   240
         120               3.2                 50/60            350             170                   240
         220               1.7                 50/60            350             170                   240
         230               1.6                 50/60            350             170                   240
         240               1.5                 50/60            350             170                   240

   No load speed                        6409               2200rpm
                                        6410               0-2200rpm
   Drill chuck capacity                 6409               1.5-10mm(1/16-3.8")
                                        6410               1.0-10mm(1/32-3.8")
   Max.drilling                         Steel              10mm(3/8")
   capacities                           Wood               25mm(1")
   Net weight                                              1.2Kg(2.6lbs)
   Cord length                                             2.0m(6.6ft)

      Standard equipment
       Chuck Key S10 (Model 6409 only)


      Optional accessories
       Drill bit 1.5,2,3,4,5,6
       Drill bit for wood 9,12,15


       Features and benefits
       1. Double insulated
       2. See the attached sheets for more information.




The standard equipment for the tools shown may differ from country to country.
(1)   6409

             Conventional(Keyed) drill chuck




                                                            Ergonomic design
                                                             for easilly pushing
                                                             axis of drilling




                                    On-Off switch
                                     with large trigger




(2)   6410




             Keyless drill chuck




                                                            Ergonomic design
                                                             for easilly pushing
                                                             axis of drilling




                                      variadle speed
                                      control switch
                                       with large trigger
                                       and the lever for
                                       changing direction
Repair
Use cares of the following points in assembling/disassembling.

1)   See the figure below for the positions of ball bearing seal.


2)   Assemble the shaft receiver of the commutator side as shown on the below figure.


                                                                                       O ring 11

                                                                         Fiber washer 6            Oil less bearing 6




                                                                                                           Plate 12
                   Seal
                                                                    Felt ring(Immerse the machine oil.)


       1) Positions of ball bearing seal                2. Assembling of shaft receiver at commutator side
Circutt      drawing
Circuit drawing of #M606, #6409:
The condenser and line filter are not used in some countries.




                                                                                                      Field
                                                                  To field steel plate
                                             Switch
                                         1                                         Earth terminal
                         Cab tire cord




                                                                  Capsitor
                                         2      2 1   3




                                                                             Line filter




Circuit drawing of #M607, #6410:
The condenser, chalk coil and line filter are not used in some countries.




                                                                                       Orange color
                                                                    Chalk coil
                                                                                       White
                                                                                       Violet
                                         3       2                  Chalk coil                                Field
                                                                                       Yellow
                                         1      4
                                                                                     Black
                                         1     M1
                                                                     Line filter
             Cab tire cord




                                               M2

                                               C1

                                         2     C2
                                                                                           Black
Switch(Reversing switch mounted)                      Capasitor               Earth terminal

                                                                              To field steel plate
