Image preview - the first page of the document
64123-WW-1


>> Download 64123-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Addition of Needle Bearing to Blade Case Complete or Gear Housing Complete
                                                                                                           64123
                                                                                                        (Page 1 of 2)

                      4157KB, 5007B, 5007NB, 5007NBA, 5007NH, 5007NL, 5007S, 5008B, 5008NB, 5008NBA,
For Models
                      5057KB, M513
Country               All countries

Description           See below.

Needle Bearing 1010 has been assembled into Blade Case Complete or Gear Housing Complete.

                      Current                                                         New
    Needle Bearing 1010




                                Blade Case Complete or                                    Blade Case Complete or
                                Gear Housing Complete                                     Gear Housing Complete

        Needle Bearing 1010 is not pre-installed.                    Needle Bearing 1010 is pre-installed.


When replacing Needle Bearing 1010 itself, install it on the Blade Case Complete or Gear Housing Complete as
illustrated below.
                                                               Blade Case Complete or
                                                               Gear Housing Complete




                                                                  Needle Bearing 1010


                                                                  Needle Bearing 1010 should not level with this
                                                                  surface as illustrated at left, otherwise you may not
                                                                  obtain adequate clearance between Needle Bearing
                                                                  1010 and Spindle.

                                        Distance must be 22.3-22.7mm.




Interchangeability(I/C)
 Item No.      Current part                 Q'ty I/C           New part                 Q'ty            Note
           Blade Case Complete                           Blade Case Complete
                                              1     No                                    1
           152753-8                                      153304-0
                                                                                                  See note 2 below.
           Needle Bearing 1010
                                              1
See note 1 212052-1
below.     Blade Case Complete                           Blade Case Complete
                                              1     No                                    1
           151803-6                                      153303-2                                 See note 3 below.
           Needle Bearing 1010
                                              1
           212052-1
                                                                                                  64123
                                                                                                (Page 2 of 2)
Interchangeability(I/C)
 Item No.        Current part               Q'ty I/C          New part              Q'ty        Note
            Blade Case Complete                        Blade Case Complete
                                             1    No                                 1
            154321-3                                   153316-3
                                                                                           See note 4 below.
            Needle Bearing 1010
                                             1
            212052-1
            Blade Case Complete                   No   Blade Case Complete
                                             1                                       1
            154322-1                                   153305-8                            See note 5 below.
            Needle Bearing 1010
                                             1
            212052-1
            Blade Case Complete                        Blade Case Complete
                                             1    No                                 1
 See note 1 152628-1                                   153307-4
                                                                                           See note 6 below.
 below.     Needle Bearing 1010
                                             1
            212052-1
            Blade Case Complete                   No   Blade Case Complete
                                             1                                       1
            152630-4                                   153306-6                            See note 7 below.
            Needle Bearing 1010
                                             1
            212052-1
            Gear Housing Complete                 No   Gear Housing Complete
                                             1                                       1
            152926-3                                   153302-4                            See note 8 below.
            Needle Bearing 1010
                                             1
            212052-1

Note
1. Item No. for Blade Case Complete or Gear Housing Complete
    Model 4157KB 5007B 5007NB 5007NBA 5007NH 5007NL 5007S 5008B 5008NB 5008NBA 5057KB M513
   Item No. 033   032    033     033    034    034   032   034    034    034     033  032

  Item No. for Needle Bearing 1010
    Model 4157KB 5007B 5007NB 5007NBA 5007NH 5007NL 5007S 5008B 5008NB 5008NBA 5057KB M513
   Item No. 035   042    042     042    016    016   042   018    018    018     035  042

2. For 5007B, 5007NB, 5007S, M513 manufactured in MJ (Makita Japan) and 5007NB, 5007NBA manufactured in
   MCC (Makita (China) Co., Ltd.)
3. For 5007NB, 5007NBA manufacutred in MCT (Makita Canada, Inc.)
4. For 5007NB, 5007NBA manufacutred in MCA (Makita Corporation of America)
5. For 5008B, 5008NB manufacutred in MJ (Makita Japan) and 5008NB, 5008NBA manufactured in MCT (Makita
   Canada, Inc.)
6. For 5007NH manufactured in MCA (Makita Corporation of America)
7. For 5007NL manufactured in MCA (Makita Corporation of America)
8. For 4157KB, 5057KB manufacutred in MCA (Makita Corporation of America)

Implementation
Machines manufactured in MJ (Makita Japan)
5007B : Discontinued since Oct., 1993
5007NB: From serial No. 1383260E (Oct., 2001)
5007S : From serial No. 2001E (Aug., 2001)
5008B : From serial No. 119873E (Aug., 2001)
5008NB: Discontinued since Oct., 1993
M513 : Discontinued since June, 1991
Machines manufactured in MCA (Makita Corporation of America)
To be informed later
Machines manufactured in MCC (Makita (China) Co., Ltd)
To be informed later
Machines manufactured in MCT (Makita Canada, Inc.)
To be informed later
