Image preview - the first page of the document
64427-WW-1


>> Download 64427-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Stopper Pin
                                                                                                           64427


For Models              LS0711B, LS0811, LS1011, LS1013, LS1212
                        Note: This Technical Information does not apply to LS1013 and LS1212 for Canada, Mexico,
                        U.S.A., Brazil, Chile and Panama
Country                 All countries

Description             Stopper Pin has been changed as illustrated below.

                         Current                                                     New




          Stopper Pin                                                   Knob 20 Stopper Pin


Interchangeability(I/C)
 Item No.        Current part                Q'ty I/C            New part                Q'ty           Note
            Stopper Pin                                  Stopper Pin
    031                                         1   No                                    1
            322317-4                                     322338-6                                  For LS0711B
                                                                                                   Interchangeable
                                                         Knob 20
    136                                                                                   1        as a set
                                                         271601-3
See note 1 Stopper Pin                                   Stopper Pin
                                                1   No                                    1     For LS0811, LS1011,
below.     322317-4                                      324183-5
                                                                                                LS1013
See note 2                                               Knob 20                                Interchangeable as a set
                                                                                          1
below.                                                   271601-3
           Stopper Pin                                   Stopper Pin
   091                                          1   No                                    1
           322988-7                                      322629-5                                  For LS1212
                                                                                                   Interchangeable
                                                         Knob 20                          1        as a set
    161
                                                         271601-3

Note
1. Item No. of Stopper Pin
    For Model LS0811 LS1011 LS1013
     Item No.  105     40     91

2. Item No. of Knob 20
    For Model LS0811 LS1011 LS1013
     Item No.  167    148    165

Implementation
Machines manufactured in MJ (Makita Japan)
LS0711B, LS0811, LS1212: To be informed later
LS1011: Discontinued since May, 1999
LS1013: From serial No. 117229E (Aug., 2001)
