Image preview - the first page of the document
64547-WW-1


>> Download 64547-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Switch
                                                                                              64547

                     4300BV, 4301BV, 4320, 6010BVR, 6310, 6402, 6510LVR, 6800DBV, 6801DBV, 6802BV,
For Models
                     6805BV, 800, DP4700, M800, M802
Country              All countries
                     Switch has been changed as shown below.
Description
                     (The way of installing switch and wiring remains unchanged.)

    Switch for 100-120V countries

                                    Current                                      New
  Manufacturer                      CAPAX                                    FUJISOKU

  Cat. No.                           11-12                                 SGEL108CV-1A

  Rated                        6(6)A 125V AC                               8(8)A 125V AC

  Part No.                          651246-7                                  651255-6

    Switch for 220-240V countries

                                    Current                                      New
  Manufacturer                      CAPAX                                    FUJISOKU

  Cat. No.                           11-12                                 SGEL106CV-1A

  Rated                        6(6)A 250V AC                               6(6)A 250V AC

  Part No.                          651247-5                                  651256-4


Interchangeability(I/C)
 4300BV, 6402, 6800DBV, 6802BV, 6805BV, DP4700, M800
 Item No.       Current part            Q'ty I/C         New part                    Q'ty      Note
           Switch                                 Switch                                     100-120V
See below                                1 Yes                                           1
           651246-7                               651255-6                                   Countries

 4301BV, 4320, 6010BVR, 6310, 6402, 6510LVR, 6800DBV, 6801DBV, 6802BV, 6805BV, 800, DP4700, M800, M802
 Item No.       Current part              Q'ty I/C        New part                  Q'ty     Note
          Switch
See below                                  1 Yes Switch                              1     200-240V
          651247-5                                 651256-4                                Countries

Item No. of Switch
Model    4300BV 4301BV        4320      6010BVR   6310   6402   6510LVR 6800DBV 6801DBV       6802BV
Item No.   060    069          006         013     010    039     040      036     036          039

Model    6805BV DP4700        M802
Item No.   054   037          028

Implementation
4320: From serial No. 491060E (Sep., 2001)
6310: From serial No. 46980E (Sep., 2001)
6510LVR: From serial No. 807144E (Sep., 2001)
6802BV: From serial No. 368525E (Sep., 2001)
6805BV: From serial No. 175392E (Sep., 2001)
DP4700: From serial No. 722817E (Sep., 2001)
The remaining models: To be informed later.
