TECHNICAL INFORMATION
Subject                Change of Swash Bearing 10
                                                                                                        64573


For Models             BHR200
Country                All countries

Description            Swash Bearing 10 has been changed as illustrated below.


                       Current                                                      New




                              57.0 mm (2-1/4")                                         58.5 mm (2-5/16")




Note: New Swash Bearing 10 is available now as a replacement part. But either the current Swash Bearing 10 or the new
      one will be used to assemble BHR200 at our factory for a while.

Interchangeability(I/C)
Item No.       Current part              Q'ty I/C            New part                 Q'ty           Note
           Swash Bearing 10                1           Swash Bearing 10
    041                                          Yes                                    1
           219013-2                                    219014-0


Implementation
To be informed later
