TECHNICAL INFORMATION
Subject                 Change on Dampproof Material on Hall Circuit Complete
                                                                                                               64574


For Models              4604D
Country                 All countries
Description             The dampproof material has been replaced by the one which is more durable
                        against anticorrosive oil.

                                                          New
           The new Hall Circuit Complete can be distinguished from the old one by the marking of the date
           of production illustrated below.


                           Description of Parts No.


                            Marking of the date of production.
                              1       9         0 5               This marking of 1905 means that this part was
                                                                  produced on " September 5th, 2001".
                                                                  See below for how to read this mark.


                                                        The numbers in the 3rd and 4th digits mean
                                                        the day of the month.
                                                          01 - 31 = 1st.-31st.
                                                        The number in the second digit means the month.
                                                          1 - 9 = Jan. - Sept.
                                                        Oct. to Dec. are expressed as follows.
                                                          Oct. = X, Nov. = Y, Dec. = Z
                                                        The number in the first digit means the last digit of the year.
                                                          9 = 1999, 0 = 2000, 1 = 2001, .........., 8 = 2008




Interchangeability(I/C)
Item No.         Current part                Q'ty I/C           New part                     Q'ty           Note
           Hall IC Circuit Complete            1        Hall IC Circuit Complete               1
    024    631365-5                                     631365-5
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Note
On and after 5th September 2001 production, the new water proof material is applied to Hall Circuit Complete.
