64502-WW-1


>> Download 64502-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Tool Retainer and Tool Retainer Shaft
                                                                                                                 64502


For Models             HM1800

Country                All countries

Description            Tool Retainer and Tool Retainer Shaft have been modified as illustrated below.
                       The method to install the bit without a collar has been changed.


                                                                                            Current
                                                 Tool Retainer
                                                    Shaft

                                                                                      The bit without a collar


          Tool Retainer                                              Install the             Pivot the
                                 Cross section                       bit without a           Tool Retainer
                                                                     collar.                 back toward
          Current                          Current                                           the Cylinder.

                                                         Flat




                                                                                              New

           New                               New

                                                       Round




Interchangeability(I/C)
Item No.      Current part              Q'ty I/C   New part                    Q'ty                  Note
           Tool Retainer                      Tool Retainer
    078                                  1 No                                    1 When replacing one of these two new
           322478-0                           324236-0
                                                                                   parts, also replace the other with the
           Tool Retainer Shaft                Tool Retainer Shaft
    079                                  1 No                                    1 new part.
           322550-8                           324238-6


Note
For the bit with a collar, the method to install it remains unchanged.




             The bit with a collar

Implementation
From serial No.22459E (Sep.,2001)
