Image preview - the first page of the document
64679-WW-1


>> Download 64679-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Tapping Screws, Gear Housing Complete
                                                                                                         64679


For Models           9015A, 9015B, 9015DB, 9016B, 9016DB
Country              All countries
                     Tapping Screws Mx16 for securing Bearing Box to Gear Housing Complete have been replaced by
Description
                     Pan Head Screw M5x16. Accordingly, Gear Housing Complete has been changed as shown below.


                                               Gear Housing Complete




                                              Bearing Box


                                               Tapping Screw Bind CT 5x16

                      Current                                                      New
              Tapping Screw CT5x16                                       Pan Head Screw M5x16
                    (266027-2)                                                (265096-0)

                                                                                              Adhesive applied



              Gear Housing Complete                                      Gear Housing Complete
                    (159995-5)                                                 (153374-9)




            Holes are not threaded inside.                               Holes are threaded inside.
Note: When re-fastening the current screws on the current Gear Housing Complete so as not to be loosened, apply
adhesive (Lock Tite 242 50G,Part No. 0405065-5A) inside the holes on the current Gear Housing Complete.
When replacing the current Gear Housing Complete with the unused current Gear Housing Complete, apply a bit of the
above adhesive inside those holes only after making threaded holes by screwing the tapping screws in the holes.
Interchangeability(I/C)
 Item No.      Current part                   Q'ty I/C        New part                       Q'ty          Note
          Tapping Screw CT5x16                         Pan Head Screw M5x16
See below                                      4    No                                         4
          266027-2                                     265096-0                                       Interchangeable
            Gear Housing Complete                      Gear Housing Complete                               as a set
    004                                        1    No                                         1
            159995-5                                   153374-9
Item No. of Tapping Screw
Model    9015A       9015B 9015DB 9016B 9016DB
Item No.  020         019    019   019    019

Implementation
9015A: From serial No. 2126E (Oct., 2001)
9015B: From serial No. 110993E (Oct., 2001)
9015DB: From serial No. 23699E (Oct., 2001)
9016B: From serial No. 27315E (Oct., 2001)
9016DB: From serial No. 9210E (Oct., 2001)
