Image preview - the first page of the document
64624-WW-1


>> Download 64624-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Tapping Screw
                                                                                                      64624


For Models           9031
Country              All countries
Description          Tapping Screws 4x18 for securing Handle Cover, Tapping Screw M4x25 for securing Gear Housing
                     Complete and Tapping Screw 4x60 for securing Field have been changed as shown below.



                                        Handle Cover


                            Tapping Screw
                                4X18

                                                                                        Field


                                                                                      Tapping Screw
          Tapping Screw                                                                   4X60
             M4X25




Interchangeability(I/C)
 Item No.            Current part                Q'ty I/C          New part                      Q'ty   Note
             Tapping Screw M4x25                           Tapping Screw M4x25
    005                                            3   Yes                                        3
             265924-9                                      265999-8
             Tapping Screw Bind BT 4x60                    Tapping Screw 4x60
    047                                            2   Yes                                        2
             265988-3                                      266052-3
             Tapping Screw 4x18                            Tapping Screw 4x18
    023                                            3   Yes                                        3
             265941-9                                      265995-6

Implementation
From serial No. 79025E (Sep., 2001)
