Image preview - the first page of the document
64747-WW-1


>> Download 64747-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Spindle and Addition of Retaining Ring S-15
                                                                                                         64747

For Models           5007NB, 5007NBA, 5007NH, 5007NL, 5007S, 5007F, 5007FA, 5057KB, 4157KB
Country              All countries
Description          Retaining Ring S-15 has been added. Accordingly, a groove for installing this Retaining Ring
                     has been added on Spindle.

                      Current                                                        New
                     Helical Gear 39                     Retaining Ring S-15       Helical Gear 39


                                                                                                      Spindle
                                                                                                     (Groove has
                                                                                                     been added.)
                                              Spindle




                        Bearing Box                                                   Bearing Box

Interchangeability(I/C)
  For Models 5007NB, 5007NBA, 5007NH, 5007F, 5007FA, 5007S
Item No.       Current part                 Q'ty I/C          New part                       Q'ty        Note
See below Spindle                                     Spindle
                                              1    No                                         1
          324044-9                                    324256-4
See below                                               Retaining Ring S-15                   1
                                                        961055-9
Item No. for Spindle (324256-4)
Model 5007NB 5007NBA 5007NH 5007F 5007FA 5007S
Item No. 028          028       011    028  028 027
Item No. for Retaining Ring S-15 (961055-9)
Model 5007NB 5007NBA 5007NH 5007F 5007FA 5007S
Item No. 028          028       011    028  028 027
  For Model 4157KB
 Item No.        Current part               Q'ty I/C         New part                        Q'ty        Note
            Spindle
    041                                       1    No Spindle                                 1
            324044-9                                  324257-2
    089                                                 Retaining Ring S-15                   1
                                                        961055-9
  For Model 5007NL
 Item No.        Current part               Q'ty I/C            New part                     Q'ty        Note
            Spindle
    011                                       1    No Spindle                                 1
            324045-7                                  324258-0
    089                                                 Retaining Ring S-15                   1
                                                        961055-9
  For Model 5057KB
 Item No.        Current part               Q'ty I/C          New part                       Q'ty        Note
    041     Spindle                           1    No Spindle                                 1
            324133-0                                  324257-2
                                                        Retaining Ring S-15
    036                                                                                        1
                                                        961055-9

Implementation
5007NB: From serial No. 1383260E (Oct., 2001)
The remaining Models: To be informed later.
