Image preview - the first page of the document
64794-WW-1


>> Download 64794-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Modification of Terminal Unit
                                                                                                          64794


For Models           BTD040, BTD042, BTD060, BTD062, BTW070, BTW072
Country              All countries

Description          Terminal Unit has been modified as illustrated below.

                 Terminal Unit

                                                                                      Current              New
                                                   1

                                                            Width of 1, 2, 3, 4        2.0mm             1.5mm



                                       4                                                            Lowered by 0.4mm
                                                          Position of Connector       See left.     than the current.
  3                                   Connector



                          2

Interchangeability(I/C)
Item No. Current part                Q'ty I/C    New part                 Q'ty                    Note
        Terminal Unit                         Terminal Unit                       For BTD040,
   005                                    Yes                              1
        638016-1                              638016-1                            BTD060, BTW070 Part No. remains
          Terminal Unit                         Terminal Unit                     For BTD042,    unchanged.
    005                                   Yes                              1
          638085-2                              638085-2                          BTD062, BTW072


 Implementation
BTD040: From serial No.1745E (The implemention date will be informed later.)
BTD042: From serial No.1523E (Jan.,2002)
BTD060: From serial No.1744E (The implemention date will be informed later.)
BTD062: From serial No.1475E (Jan.,2002)
BTW070: From serial No.1476E (The implemention date will be informed later.)
BTW072: From serial No.,1270E (The implemention date will be informed later.)
