TECHNICAL INFORMATION
Subject                Change of Fan 65, Clamper
                                                                                                              64732


For Models             BO4540 (only for China), BO4560, M904
Country                All countries
Description            Fan 65 has been changed.
                       Clamper has also been changed.
    Change of Fan 65
                         Current                                                        New



                                                  View from A                                                View from B




                                       Straight                                                    Taper




         Straight                                                      Curved
                          Fan 65                                                      Fan 65
                        (241653-8)                                                  (241666-9)

  Change of Clamper

                         Current                                                       New




                                                                     The surface has been raised in these areas.



Interchangeability(I/C)

  Item No.       Current part                         Q'ty I/C          New part                      Q'ty         Note
BO4540: 007 Fan 65                                               Fan 65
                                                       1                                                1
BO4560: 007 241653-8                                             241666-9
M904: 010
BO4540: 012 Clamper                                              Clamper Complete
                                                       2                                                2
M904: 012   155957-1                                             153384-6
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
Change of Fan 65:
To be informed later.
Change of Clamper:
BO4540: From serial No. 148380E (Oct., 2001)
BO4560: Discontinued since Apr., 1995
M904: Discontinued since Jun., 1992
