Image preview - the first page of the document
64832-WW-1


>> Download 64832-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject
                                                                                                         64832
                       Change of Color of Capsule, Housing Set, Nozzle Assembly, Corner Nozzle, Shelf Brush etc.
For Models             4070D, 4071D, 4072D, 4073D, 4090D, 4014N, 4014NV, 4090D, 4091D, 4092D, 420, 420S, 450,
                       451, DK1001, M010, M400, M401, UB1100, UB120D, UB121D, UB140D, UB141D, UB181D,
                       UB1101
Country                All countries
Description            Color of resin used for the parts shown in the Interchangeability below has been changed
                       from almond to ivory. Part No. of these parts remains the same.

                                                         Nozzle Assembly
                                                         Upper Nozzle


                                                                           Joint
                                          Under Nozzle


Interchangeability(I/C)
Item No.         Current part              Q'ty I/C             New part                  Q'ty           Note
           Capsule                                     Capsule
                                             1   Yes                                        1    For 4070D, 4071D
           134294-6                                    134294-6
           Housing Set                                 Housing Set
                                             1   Yes                                        1    For 4070D
           181553-9                                    181553-9
           Housing Set                                 Housing Set
                                             1   Yes                                        1    For 4071D
           181727-2                                    181727-2
           Nozzle Assembly                             Nozzle Assembly                      1
                                             1   Yes
           122291-4                                    122291-4
           Nozzle Assembly                             Nozzle Assembly
                                             1   Yes                                        1
           122234-6                                    122234-6
           Corner Nozzle                               Corner Nozzle                             See below for
                                             1   Yes                                        1
           411891-8                                    411891-8                                  models in which
           Straight Pipe                     1   Yes   Straight Pipe                             these parts are used
                                                                                            1
           412040-0                                    412040-0
           Shelf Brush                       1   Yes   Shelf Brush
                                                                                            1
           191724-0                                    191724-0
           Flexible Hose Set                 1         Flexible Hose Set                    1
                                                 Yes
           191750-9                                    191750-9

 Note
     New Part     Part No.                                For Model
Nozzle Assembly 122291-4 M010, 4070D, 4071D, 4073D, 4091D, 4092D
Nozzle Assembly 122234-6 DK1001, 4070D, 4071D, 4090D, 4091D, 4092D, 420, 420S
                           DK1001, M400, M401, UB1100, UB120D, UB121D, UB140D, UB141D, UB181D,
Corner Nozzle     411891-8 4014N, 4014NV, 4070D, 4071D, 4090D, 4091D, 4092D, 420, 420S, 450, 451
                           4070D, 4071D, 4090D, 4091D, 4092D, 4014N, 4014NV, 420, 420S, 450, 451, DK1001,
Straight Pipe     412040-0
                           M400, M401, UB1100, UB1101, UB120D, UB121D, UB140D, UB141D, UB181D
Shelf Brush       191724-0 M010, 4070D, 4071D, 4072D, 4073D, 4091D, 4092D, 420, 420S
                           4070D, 4071D, 4090D, 4091D, 4092D, 4014N, 4014NV, 420, 420S, 450, 451, DK1001,
Flexible Hose Set 191750-9
                           M400, M401, UB1100, UB1101, UB120D, UB121D, UB140D, UB141D, UB181D

Implementation
4070D: From serial No. 58438E (Oct., 2001)
4071D: From serial No. 582751E (Dec., 2001)
4090D, 4091D: Discontinued since May 1984
4091D: Discontinued since May 1995
4092D: Discontinued since Sep.,2000
The remaining models: To be informed later
