Image preview - the first page of the document
64978-WW-1


>> Download 64978-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject                Change of Cord Guard
                                                                                                           64978


For Models             9227C, 9927CB
Country                All countries
Description            Cord Guard has been changed in diameter at the neck from 17 mm (11/16") to 19 mm (3/4").


                        Current                                                         New
                     Cord Guard                                                    Cord Guard
                      (682502-4)                                                    (682503-2)



                                    Neck diameter:                                           Neck diameter:
                                    17 mm (11/16")                                           19 mm (3/4")


Interchangeability(I/C)
    9227C (for Canada, USA, Mexico, Panama, Kuwait, Saudi Arabia (127V, 220-240 V), Turkey, Congo, Gabon,
    Morocco, Canary Islands, Indonesia, Malaysia, Singapore, Guam, New Caledonia, Tahiti)
   9227CB (for Argentina, Austria, France, Italy, Netherlands, Spain, Switzerland, U.K. (110V, 240V), Bhutan, Algeria,
         Kuwait, Reunion, Saudi Arabia (220-240 V), South Africa, China, Hong Kong)
 Item No.          Current part                    Q'ty I/C            New part                    Q'ty     Note
9227C: 031 Cord Guard                                         Cord Guard
                                                    1                                               1
9227CB: 029 682502-4                                          682503-2


    9227C (for Bolivia, Brazil (110V, 220V), Chile, Paraguay, Peru, Uruguay, Syria, North Korea, Philippines,
          Thailand, Viet Nam)
    9227CB (for Australia, New Zealand)
 Item No.            Current part                    Q'ty I/C          New part                    Q'ty         Note
                Cord Guard                                      Cord Guard
9227C: 031                                            1                                              1
                682504-0                                        682505-8
9227CB: 029


    9227CB (for Germany, Russia, Sweden, South Korea)
 Item No.       Current part                         Q'ty I/C          New part                    Q'ty         Note
9227C: 031 Cord Guard                                           Cord Guard
                                                      1                                              1
9227CB: 029 682516-3                                            682540-6

Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
  9227C (for Canada, U.S.A., Mexico, Panama, Kuwait, Saudi Arabia (110V, 220-240 V), Turkey, Congo,
         Morocco, Canary Islands, Indonesia, Malaysia, Singapore, Guam, New Caledonia, Tahiti):
         From serial No. 127966E (Nov., 2001)
 9227CB (for Argentina, Austria, France, Italy, Netherlands, Spain, Switzerland, U.K. (110V, 240V), Bhutan, Algeria,
       Kuwait, Reunion, Saudi Arabia (220-240 V), South Africa, China, Hong Kong):
        From serial No. 69160E (Nov., 2001)
 9227C (for Bolivia, Brazil (110V, 220V), Chile, Paraguay, Peru, Uruguay, Syria, North Korea, Philippines,
       Thailand, Viet Nam):
       To be informed later.
 9227CB (for Australia, New Zealand): From serial No. 68890E (Nov., 2001)

 9227CB (for Germany, Russia, Sweden, South Korea): From serial No. 69310E (Nov., 2001)
