Image preview - the first page of the document
64917-WW-1


>> Download 64917-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Gear Cover
                                                                                                          64917


For Models           9900B, 9924B, 9924DB
Country              All countries
Description          See below.
Rubber Pin 4 (a constituent part of Gear Cover Complete) has been eliminated. Consequently, new Gear Cover has no
hole for Rubber Pin 4.
Note: Rubber Pin 4 is necessary for the current Gear Cover Complete (Pt. No. 152206-7). When using the current Gear
      Cover Complete, do not remove the Rubber Pin 4 from it.

                      Current                                                      New
              Gear Cover Complete                                           Gear Cover
                              Ball Bearing 6200LLB                                      Ball Bearing 6200LLB
      Hole for
     Rubber Pin 4                                                 No hole
                                       Helical Gear 10                                             Helical Gear 10




                       Rubber Pin 4



Interchangeability(I/C)
 Item No.       Current part                  Q'ty I/C          New part                    Q'ty         Note
9900B: 062 Gear Cover Complete                           Gear Cover
                                                1    Yes                                      1
9924B: 050 152206-7                                      312808-3
9924DB: 049


Implementation
9900B: Discontinued since May, 2001
9924B: Discontinued since Apr., 1993
9924DB: To be informed later
