Image preview - the first page of the document
65031-WW-1


>> Download 65031-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Keyless Drill Chuck 10
                                                                                                           65031


For Models              6203D, 6213D, 6233D, DK1022
                        Note: This Technical Information applies to machines manufactured in MCA plant.
Country                 All countries
Description             Keyless Drill Chuck 10 has been changed as illustrated below.

                          Current                                                        New




               Keyless Drill Chuck 10 Set                                    Keyless Drill Chuck 10 Set
               (Manufacturer: JACOBS)                                         (Manufacturer: ROHM)



Interchangeability(I/C)
 Item No.         Current part                   Q'ty I/C        New part                    Q'ty         Note
           Keyless Drill Chuck 10 Set                    Keyless Drill Chuck 10 Set
6203D: 017                                         1 Yes                                       1 For all countries
           192889-1                                      193694-9                                except North America
6213D: 015
6233D: 017 Keyless Drill Chuck 10                  1 Yes
                                                            Keyless Drill Chuck 10 Set
                                                                                               1 For North America
           192889-1                                         193692-3

Implementation
To be informed later.
