TECHNICAL INFORMATION
Subject               Change of Anvil
                                                                                           65143


For Models            6908D, 6913D, 6914D, 6950, 6951, 6970D

Country               All countries

Description           Anvil has been changed as illustrated below.
                               Hammer Case Complete
                                                    Steel Ball 3.5


                                                              Anvil
                                                                      Hammer




                                        Nylon Washer 14




                       Current                                                 New




                                                                                           Rounded




Interchangeability(I/C)
 Item No.       Current part                Q'ty I/C              New part       Q'ty    Note
           Anvil                                            Anvil
See below.                                      1                                    1
           322754-2                                         324267-9
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.
Item No. of Anvil
 Model No. 6908D 6913D 6914D             6950       6951 6970D
 Item No.    021  008   021              008        015   021


Implementation
6908D, 6913D, 6914D, 6951, 6970D: To be informed later
6950: Discontinued since May, 1999
