6510B2-TE


>> Download 6510B2-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.            6510B-2
                                                                                                                 New Tool


     Description           MAKITA 10mm(3/8") 2-speed Dril

CONCEPTION AND MAIN APPLICATIONS
  This machine has been developed according to our salesmen's
  request for less expensive double transmission. The model is for
  export only, and the works suitable for drill diameter or holing
  materials can be done so that the efficiency is improved.




  Specifications
        Voltage (V)               Current (A)               Frequency (Hz)             Continuous rating input (W)
      Single phase 100              3.5                        50-60                            330

    Electric motor                      series commutator motor
    Rotation per minute                 High Speed/2300 rpm, Low Speed/950 rpm
    Max. drilling capability            Iron      10 mm
                                        Wood      21 mm
    Total length                        285 mm
    Net weight                          1.6 kgs
    Power supply cord                   2.5m



  Standard equipment
   Chuck key complete S10



  Features and benefits
   (1) Because of double transmission, the works suitable for drill diameter or material can be done and efficiency
       is improved.
   (2) Since it is small and light, you can use it easily and the structure is double insulation which is safe
       electrically.
   (3) You can use it in wide range of works owing to the attachment method.
   (4) You can keep or carry it because a carry hook is applied.


  Capacity

                                       Model           6510B-2                  6000R            6510PBL
  Material to be shaved
                          Drill diameter       H (2300rpm) L (950rpm)       (10~2600rpm)         (1050rpm)
        Soft steel                 6.5         3.4 A 20 SEC 2.7 A 46 SEC           A      SEC         A    SEC

        t=12mm                     10          4     31     3.1   65         3.8        35      3.8       60
        Cast iron                  6.5         3.1   22     2.6   45
        t=24mm                     10          3.8   33     2.8   75         3.9        33      2.8       68
        Aluminum                   6.5         3     17     2.5   33
        t=24mm                     10          3.6   20     2.8   38         3.9        23      2.8       30

   The standard equipment for the tools shown may differ form country to country.

                                    Model                     6510B-2
Material to be shaved
                        Drill diameter           H               L
                                                 A    SEC
                                 12         3.5      2      2.7 A 3 SEC
                                 15         4        2      3        3
     Lauan                       18         4.8      2.5    3.1      3
     t=60mm                      21         5~6      3      3.8      4
                                 24         6.5~7 4         3.8      4
                                 30         Motor rock      5~5.5 5
                                 12         3.7      2      2.8      4
                                 15         4.2      2      3.2      4
     Hemlock                     18         5        2.5    35       4
     t=60mm                      21         6.2(7.5) 3      4(4.6) 4.5
                                 24         6.5(8) 4        4(4.7) 4.5
                                 30         Motor rock      5.2(6.5) 6
  For drilling in metal ones, H is suitable. Comparing to #6000R,
        H has higher efficiency.

          The capacity in wood works: in high speed(H) 13mm, in low speed(L) 21mm,
       in terms of load current and using feeling.

Note in assembly
a. Assembly procedure of Shifter and Spindle parts
(1) Attach Shifter part.                                       Fig.    -B                      Fig.    -A
(2)Insert Spar gear 29
(3) Attach Spindle part (See Fig 1 )




b. Relation between Shifter and Rotation Display of Handle
When Handle is in the condition of Fig.II-A against Gear-housing,                              Fig 1
the relation between Handle and Shifter is shown as Fig.II-B.




                                                                            Distinguish here




               Fig.   -A                                        Fig.   -B

c. Applying of Grease
Grease should be applied in Gear part as well as between Ring 16
and Pin 4.
        (Total quantity of grease: 15 g)
