TECHNICAL INFORMATION
Subject               Addition of Safety Wire, Change of Pan Head Screw
                                                                                                      65112


For Models            4300BV

Country               U.K.
Description           1)To comply with British Standard, Safety Wire has been added.
                      2)Pan Head Screws have been changed for securing the Safety Wire on Gear Housing Cover.
                      See the illustration below.


                                                                  Current                        New
                                                           Pan Head Screw M4x20        Pan Head Screw M4x20
                                                            (With Spring Washer)      (With Spring Washer and
                                                                 (911136-9)                 Flat Washer)
                                                                                             (911138-5)




                                                                  Added
                                                                Safety Wire
                                                                (324272-6)




Interchangeability(I/C)
 Item No.       Current part                  Q'ty I/C          New part                 Q'ty         Note
                                                          Safety Wire
    063                                                                                    1
                                                          324272-6

    029     Pan Head Screw M4x20                          Pan Head Screw M4x20             4
                                                4
            911136-9                                      911138-5
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
From serial No.814388E (Dec.,2001)
