Image preview - the first page of the document

>> Download 65497-WW-1 documenatation <<

Text preview - extract from the document
Subject                Change of Wheel Cover

For Models             9047, 9047S, 9057, 9057S, 9047L
Country                All countries

Description            Wheel Cover has been changed as shown below.

                        Current                                              New

                       Band has bent portion in this area.

Item No.       Current part                    Q'ty I/C           New part         Q'ty   Note
           Wheel Cover                                    Wheel Cover
  030                                            1    Yes                           1
           165185-0                                       165215--7

To be informed later
