Image preview - the first page of the document
65531-WW-1


>> Download 65531-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Keyless Drill Chuck 13 and Hex. Socket Head Bolt
                                                                                                            65531

                        6313D, 6333D
For Models
                        Note: This Technical Information applies to machines manufactured in MCA plant.
Country                 All countries

Description             Keyless Drill Chuck 13 and Hex. Socket Head Bolt have been changed as illustrated below.

                             Current                                                    New

            32 mm (1-1/4")                                           21mm (13/16")




  Hex. Socket Head Bolt        Keyless Drill Chuck 13 Set      Hex. Socket Head Bolt      Keyless Drill Chuck 13 Set
         M5x32                 (Manufacturer: JACOBS)                 M5x21                (Manufacturer: ROHM)



Interchangeability(I/C)
For all countries except North America
 Item No.             Current part                Q'ty I/C            New part                   Q'ty        Note
6313D: 015 Keyless Drill Chuck 13 Set                      Keyless Drill Chuck 13 Set
                                                    1   No                                        1
6333D: 017 192891-4                                        193695-7
                                                                                                        Interchangeable
           Hex. Socket Head Bolt                           Hex. Socket Head Bolt
6313D: 016 M5x32                                                                                             as a set
                                                    1   No M5x21                                  1
6333D: 018
           266154-5                                        265998-0

For North America
 Item No.             Current part                Q'ty I/C            New part                   Q'ty        Note
6313D: 015 Keyless Drill Chuck 13 Set                      Keyless Drill Chuck 13 Set
                                                    1   No                                        1
6333D: 017 192891-4                                        193693-1
                                                                                                        Interchangeable
           Hex. Socket Head Bolt                           Hex. Socket Head Bolt
6313D: 016 M5x32                                                                                             as a set
                                                    1   No M5x21                                  1
6333D: 018
           266154-5                                        265998-0


Implementation
To be informed later.
