Image preview - the first page of the document
65636-WW-1


>> Download 65636-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Grip Base and Addition of Hex. Washer
                                                                                                         65636

                       HP2050, HP2050F, HP2051, HP2051F, HR2020, HR2021, HR2022, HR2440, HR2441, HR2442,
For Models
                       HR2450, HR2451, HR2452
Country                All countries
                       Slit in Grip Base has been eliminated and Hex. Washer has been added
Description
                       so that Stopper Pole can be secured more firmly.

                         Current                                                      New


                                                                          Hex. Washer

             Grip Base
                                                                        Grip Base



                                   Slit
                                                                                              No slit




Interchangeability(I/C)
 Item No.      Current part               Q'ty I/C       New part              Q'ty               Note
             Grip Base                               Grip Base
                                           1                                    1     Part No. remains unchanged.
             417630-4                                417630-4
                                                     Hex. Washer
                                                                                1
See below.                                           345280-4
             Grip 36 Assembly                        Grip 36 Assembly                 New Grip 36 Ass'y includes a
                                           1                                    1     Hex. Washer (Pt. No. 345280-4).
             134943-5                                134943-5
                                                                                      But part No. of Grip 36 Ass'y
                                                                                      remains unchanged.
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.
Item No. of Grip Base
  Model HP2050 HP2050F            HP2051 HP2051F         HR2020 HR2021 HR2022 HR2440              HR2441 HR2442
 Item No. 011    011                011    011            008    008    008    008                 008    008
  Model HR2450           HR2451   HR2452
 Item No. 008             008      008
Item No. of Hex. Washer
   Model HP2050 HP2050F           HP2051 HP2051F         HR2020 HR2021 HR2022 HR2440              HR2441 HR2442
  Item No.   060        060        060     060            078    078     078   078                 078    078
  Model HR2450           HR2451   HR2452
 Item No. 090             090      090
Item No. of Grip 36 Assembly
   Model HP2050 HP2050F           HP2051 HP2051F         HR2020 HR2021 HR2022 HR2440              HR2441 HR2442
  Item No.   012        012        012     012            009    009    009    009                 009    009
  Model HR2450           HR2451   HR2452
 Item No. 009             009      009

Implementation
To be informed later
