Image preview - the first page of the document
65742-WW-1


>> Download 65742-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Flat Washer 8
                                                                                                 65742


For Models           3701, 3702, 3702B, 3703, 3704, 3707, 3707F, 3707FC, 3708, 3708F
Country              All countries
Description          Flat Washer 8 has been changed as shown below.




                                                          Flat Washer 8

                                                          Cap Square Neck Bolt M5x25

                      Current                                                    New
                        22 mm                                                   18 mm
                        (7/8")                                                 (11/16")
                        8 mm                                                     8 mm
                        (5/16")                                                  (5/16")




                     Flat Washer 8                                           Flat Washer 8
                  (Part No. 253022-1)                                     (Part No. 267248-9)

 Interchangeability(I/C)
Item No.      Current part               Q'ty I/C            New part                  Q'ty     Note
   See   Flat Washer 8                               Flat Washer 8
                                             2   Yes                                       2
 below. 253022-1                                     267248-9
Item No.
Model    3701 3702 3702B 3703 3704 3707 3707F 3707FC 3708 3708F
Item No.       041  043        042                    056  056

 Implementation
3702: From serial No. 12249E (Feb., 2002)
3704: From serial No. 26136E (Mar., 2002)
3708: From serial No. 1472E (Feb., 2002)
3708F: From serial No. 1865E (Feb., 2002)
The remaining Models: To be informed later
