Image preview - the first page of the document
65732-WW-1


>> Download 65732-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Spindle
                                                                                                             65732
                                                                                                           (Page 1 of 2)

                      9560, 9560C, 9560CV, 9561, 9561C, 9561CV, 9562, 9562C, 9562CV, 9563, 9563C, 9563CV,
For Models            9564, 9564C, 9564CV, 9564CVL, 9565, 9565C, 9565CV, 9565CVL
Country               All countries
Description           See below.
End of Spindle has been changed in dimensions. Use an arbor press to insert a new Spindle into Gear Housing Complete
as it is too tight to be inserted by hand. To distinguish the new Spindle from current one, a line has been added on it as
shown below. Part No. remains the same.

                       Current                                                         New

                                                                                                  2 mm (1/16")




                                                                                          Line




Note:
When removing or installing Gear Assembly (assembled part of Spiral Bevel Gear, O Ring, Bearing Box Complete,
Wheel Cover Base, Hex. Socket Head Bolt, Labyrinth Ring and Spindle), do as follows.

If you have difficulty removing the Gear Assembly from machine body, use a plastic hammer to strike the shaded portion
of the machine.
                                                       Strike this shaded portion with a plastic hammer.





When installing the Gear Assembly on machine body, use a plastic hammer to strike the shaded portion of the machine.

                                                       Strike this shaded portion with a plastic hammer.
                                                                                                 65732
                                                                                               (Page 2 of 2)

 Interchangeability(I/C)
Item No.        Current part            Q'ty I/C          New part             Q'ty           Note
           Spindle                                Spindle
   050                                   1    Yes                               1     See note 1 below.
           324035-0                               324035-0
           Spindle                                Spindle
   050                                   1    Yes                               1     See note 2 below.
           324036-8                               324036-8
           Spindle                                Spindle
   050                                   1    Yes                               1     See note 3 below.
           324038-4                               324038-4
           Spindle                                Spindle
   050                                   1    Yes                               1     See note 4 below.
           324043-1                               324043-1


 Note
1. For 9561, 9561C, 9561CV, 9562, 9562C, 9562CV, 9564, 9564C, 9564CV, 9564CVL, 9565, 9565C, 9565CV, 9565CVL
   For All countries except Canada, Mexico, U.S.A.
2. For 9560, 9560C, 9560CV, 9563, 9563C, 9563CV
   For All countries except Guam, U.S.A.
3. For 9561, 9561C, 9561CV, 9562, 9564, 9564C, 9564CV, 9564CVL, 9565CV
   For Canada, Mexico, U.S.A.
4. For 9560CV, 9563, 9563C, 9563CV
   For Guam, U.S.A.

 Implementation
9561CV: From serial No. 4162E (Mar., 2001)
9564CV: From serial No. 7653E (Mar., 2002)
All models other than 9561CV, 9564CV: To be informed later
