Image preview - the first page of the document
65864-WW-1


>> Download 65864-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Wheel Cover
                                                                                                         65864

                      9560, 9560C, 9560CV, 9561, 9561C, 9561CV, 9562, 9562C, 9562CV, 9563, 9563C, 9563CV,
For Models
                      9564, 9564C, 9564CV, 9565, 9565C, 9565CV
Country               All countries except for Australia, New Zealand
Description           Lever of Wheel Cover has been modified for easier operation.
                      See the illustration below.
                      Part No. remains the same.

                      Current                                                          New
                                        Lever                                                Lever




Interchangeability(I/C)
 Item No.      Current part              Q'ty I/C        New part                    Q'ty             Note
            Wheel Cover                             Wheel Cover                             For 9560, 9560C, 9560CV,
    048                                    1    Yes                                   1
            163417-9                                163417-9                                9563, 9563C, 9563CV
            Wheel Cover                             Wheel Cover                             For 9561, 9561C, 9561CV,
    048                                    1    Yes                                   1
            163418-7                                163418-7                                9564, 9564C, 9564CV
            Wheel Cover                               Wheel Cover                           For 9562, 9562C, 9562CV,
    048                                    1    Yes                                   1
            163415-3                                  163415-3                              9565, 9565C, 9565CV

Implementation
9564CV: From serial No.7845E (Mar.,2002)
The remaining models: To be informed later
