65804-WW-1


>> Download 65804-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Pipe Complete
                                                                                                            65804


For Models            4101R, 4101RH
Country               All countries
Description           For further reinforcement of its durability, Pipe Complete has been modified
                      as illustrated below.

                      Current                                                         New
                                  (Pipe holder)                                                 (Pipe holder)




                     Pipe Complete                                       Water Supply Pipe Complete
                       (150172-2)                                                (153409-6)


Interchangeability(I/C)
 Item No.          Current part                   Q'ty I/C            New part                       Q'ty   Note
            Pipe Complete                                    Water Supply Pipe Complete
    011                                            1                                                  1
            150172-2                                         153409-6
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
4101R: From serial No.13840E (Mar.,2002)
4101RH: From serial No.9375E (Apr.,2002)
