Image preview - the first page of the document
66080-WW-1


>> Download 66080-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Addition of O Ring 7, Change of Nut
                                                                                                        66080


For Models              4191D

Country                 All countries

Description             O Ring 7 has been added between Water Supply Cock Complete and Nut.
                        The Nut has been modified so that the O Ring 7 can be accepted.
                        See the illustration below.


                                                        Added




                                                       O Ring 7                      Nut
          (Water Supply Cock Complete)                 (213026-5)                 (416145-8)




                           Current                                                 New

                               6.0mm                                             5.5mm
                               (1/4")                                            (7/32")




Interchangeability(I/C)

Item No.        Current part                Q'ty I/C           New part                Q'ty          Note
                                                         O Ring 7
    070                                                                                    1
                                                         213026-5
            Nut                                          Nut                                   The part No. remains
    013                                      1                                             1
            416145-8                                     416145-8                              the same.

Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
To be informed later
