Image preview - the first page of the document
66008-WW-1


>> Download 66008-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Grease, Bearing Box, Blade Case and
                       Addition of O Ring
                                                                                                          66008


For Models             5903 (MME product), 5903R (MME and MCC products)
Country                All countries
                       Grease, Bearing Box and Blade Case Complete have been changed,
Description
                       and O Rings have been added to increase durability of Gears.



                                                                                     O Ring 32 (added)


                                                                               Blade Case Complete




                                                      O Ring 44 (added)
                                                    Bearing Box


Interchangeability(I/C)

  Item No.       Current part                  Q'ty I/C            New part                   Q'ty        Note
             Makita Grease K No. 1                          Makita Grease SG No. 0
                                               12g     No                                     12g
             042014-3A                                      042016-9A
5903: 077                                                   O Ring 32
                                                                                               1
5903R: 084                                                  213459-4                                  Interchangeable
5903: 078                                                   O Ring 44                                      as a set
                                                                                               1
5903R: 085                                                  213560-5                                 For 5903, 5903R
5903: 008 Bearing Box                                       Bearing Box                              (MME products)
5903R: 013 316564-7                             1      No                                      1
                                                            317626-4
5903: 044 Blade Case Complete                               Blade Case Complete
                                                1      No                                      1
5903R: 049 152550-2                                         153467-2
           Makita Grease N No. 1                            Makita Grease SG No. 0
                                               12g     No                                     12g
           042017-7A                                        042016-9A
                                                            O Ring 32
    084                                                                                        1
                                                            213459-4                                 Interchangeable
                                                            O Ring 44                                     as a set
    085                                                                                        1        For 5903R
                                                            213560-5
                                                            Bearing Box                              (MCC product)
             Bearing Box
    013                                         1      No                                      1
             316564-7                                       317626-4
             Blade Case Complete                            Blade Case Complete
    049                                         1      No                                      1
             152550-2                                       153467-2


Implementation
To be informed later
