TECHNICAL INFORMATION
Subject                Change of Spiral Bevel Gear
                                                                                                            66107


For Models             9525NB, 9526NB, 9526NBH, 9528NB (MCC products only)

Country                All countries
Description            Spiral Bevel Gears have been changed as illustrated below.
Spiral Bevel Gear 10
                        Current                                                        New
                                                                     Grooves have been added to distinguish
                                                                     new Spiral Bevel Gear 10 from current one.




Spiral Bevel Gear 36
                        Current                                                        New
                         "mG" is engraved                                        "mG" is not engraved


                            mG




Interchangeability(I/C)
Item No.        Current part                  Q'ty I/C            New part                     Q'ty          Note
           Spiral Bevel Gear 36                           Spiral Bevel Gear 36
    041                                        1     No                                          1
           226749-6                                       227407-7                                      Interchangeable
           Spiral Bevel Gear 10                           Spiral Bevel Gear 10                               as a set
    006                                        1     No                                          1
           226748-8                                       227408-5


Implementation
To be informed later
