Image preview - the first page of the document
66135-WW-1


>> Download 66135-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Keyless Drill Chuck
                                                                                                          66135


For Models             6207D, 6217D, 6237D, 6317D, 6337D, 6347D

Country                All countries
Description            Keyless Drill Chuck has been changed as illustrated below.

                    Current                                                New




               Black                                              Silver


Interchangeability(I/C)
For Canada, U.S.A., Mexico, Panama
Item No.        Current part                Q'ty I/C         New part               Q'ty           Note
            Keyless Drill Chuck 10                     Keyless Drill Chuck 10
    013                                      1 Yes                                   1     For 6207D, 6217D, 6237D
            763165-6                                   193690-7
            Keyless Drill Chuck 13                     Keyless Drill Chuck 13
    013                                      1 Yes                                   1     For 6317D, 6337D, 6347D
            763166-4                                   193691-5

For all countries except Canada, U.S.A., Mexico, Panama
 Item No.       Current part                Q'ty I/C         New part               Q'ty           Note
            Keyless Drill Chuck 10                     Keyless Drill Chuck 10
    013                                      1 Yes                                   1     For 6207D, 6217D, 6237D
            763165-6                                   193615-1
            Keyless Drill Chuck 13                     Keyless Drill Chuck 13
    013                                      1 Yes                                   1     For 6317D, 6337D, 6347D
            763166-4                                   193616-9


 Implementation
For Canada, U.S.A., Mexico, Panama
6207D: As soon as the current part is running out.
6217D, 6237D, 6317D, 6337D, 6347D: From initial production.
For all countries except Canada, U.S.A., Mexico, Panama
6207D: As soon as the current part is running out.
6217D,6237D: To be informed later
6317D: From serial No. 26262A
6337D: From serial No. 13722A
6347D: From serial No. 12607A
