Image preview - the first page of the document
66508-WW-1


>> Download 66508-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Addition of distinguishing number on Plate
                                                                                                                      66508


For Models             6796D, 6796FD, 6797D, 6797FD, 6798D, 6798FD

Country                All countries

Description            Plate has been changed for easy tracing of maintenance record.


                          Current                                                            New

                                                                                           5 digit distinguishing number

                            1                                                * * * * *
                                                                              1        5              Curved cut
                            5                                                     Nm
                                                                                                     Indication of "Nm"


Notes on 5 digit distinguishing number
1. The number is stamped with no concern of serial number of machine.
2. Makita plant does not control the number.
3. Replacement plate is stamped with another new number.

     Part No.             344967-5                            345171-9                                 345172-7
    For Model           6796D/6796FD                        6797D/6797FD                             6798D/6798FD
      Color                Yellow                               Blue                                     Red


                           * * * * *                          * * * * *                                * * * * *
     Shape                  1        5                         2         8                              6        12
                                Nm                                  Nm                                      Nm


Distinguishing
                   The number is stamped with no concern of serial number of machine.
   Number


Interchangeability(I/C)
Item No.         Current part                 Q'ty I/C         New part                       Q'ty           Note
           Plate                                         Plate
    054                                        1                                               1
           344967-5                                      344967-5
           Plate                                         Plate
    054                                        1                                               1
           345171-9                                      345171-9
           Plate                                         Plate
    054                                        1                                               1
           345172-7                                      345172-7
Interchangeability mark ;
The arrow      means that the new part is substituted for the current.

Implementation
As soon as the current part is running out.
