Image preview - the first page of the document
66600-WW-1


>> Download 66600-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject               Change of Armature Assembly
                                                                                                        66600
                                                                                                      (Page 1 of 2)

                      9560C, 9560CV, 9561C, 9561CV, 9562C, 9562CV, 9563C, 9563CV, 9564C, 9564CV, 9564CVL,
For Models            9565C, 9565CV, 9565CVL, BO6040, GD0800C, GD0810C
Country               All countries
Description           Armature Assembly has been changed as shown below.
                      1) Stop Ring E-4 has been replaced by Self Lock 6.
                      2) Groove for Stop Ring E-4 has been eliminated.


                                                                                     Stop Ring E-4



     Current

                                                 Groove for Stop Ring E-4


                                                                                       Self Lock 6


     New

                                        Groove for Stop Ring E-4 has been eliminated.



Interchangeability(I/C)
For 9560C, 9560CV, 9561C, 9561CV, 9562C, 9562CV
Item No.      Current part            Q'ty I/C          New part                        Q'ty          Note
         Stop Ring E-4                          Self Lock 6
   019                                 1    No                                            1
         961011-9                               259039-2                                       Interchangeable as a
         Armature Ass'y 115V                    Armature Ass'y 115V                            set of Armature A'ssy
   013                                 1    No                                            1
         515181-2                               515241-0                                       and Stop Ring E-4 or
         Armature Ass'y 220-240V                Armature Ass'y 220-240V                        Self Lock 6
   013                                 1    No                                            1
         515183-8                               515243-6

For 9563C, 9563CV, 9564C, 9564CV*, 9565C*, 9565CV*
Item No.     Current part        Q'ty I/C        New part                   Q'ty               Note
         Stop Ring E-4                     Self Lock 6
   019                             1 No                                      1
         961011-9                          259039-2
         Armature Ass'y 100V               Armature Ass'y 100V                     For U.K.110V
   013                             1 No                                      1     9564CV,
         515165-0                          515225-8
                                                                                   9565C and
                                                                                   9565CV
          Armature Ass'y 115V                   Armature Ass'y 115V                            Interchangeable as a
    013                                1   No                                1
          515166-8                              515226-6                                      set of Armature A'ssy
          Armature Ass'y 220-240V               Armature Ass'y 220-240V
                                                                                               and Stop Ring E-4 or
    013                                1   No                                1                      Self Lock 6
          515168-4                              515228-2
                                                                                                       66600
                                                                                                    (Page 2 of 2)


Interchangeability(I/C)
For 9564CVL, 9565CVL
Item No.      Current part              Q'ty I/C         New part                    Q'ty          Note
         Stop Ring E-4                           Self Lock 6
   019                                   1    No                                       1
         961011-9                                259039-2                                   Interchangeable as a
         Armature Ass'y 115V                     Armature Ass'y 115V                        set of Armature A'ssy
   013                                   1    No                                       1
         515171-5                                515236-3                                   and Stop Ring E-4 or
         Armature Ass'y 220-240V                 Armature Ass'y 220-240V                    Self Lock 6
   013                                   1    No                                       1
         515173-1                                515238-9
For BO6040
Item No.      Current part              Q'ty I/C         New part                    Q'ty          Note
         Stop Ring E-4                           Self Lock 6
   046                                   1    No                                       1
         961011-9                                259039-2                                   Interchangeable as a
         Armature Ass'y 115V                     Armature Ass'y 115V                        set of Armature A'ssy
   040                                   1    No                                       1
         515201-2                                515221-6                                   and Stop Ring E-4 or
         Armature Ass'y 220-240V                 Armature Ass'y 220-240V                    Self Lock 6
   040                                   1    No                                       1
         515203-8                                515223-2

For GD0800C
Item No.     Current part          Q'ty I/C       New part             Q'ty                        Note
         Stop Ring E-4                      Self Lock 6
   030                              1    No                                 1
         961011-9                           259039-2
         Armature Ass'y 115V                Armature Ass'y 115V
   023                              1    No                                 1
         515191-9                           515216-9                                       Interchangeable as a
         Armature Ass'y 115V                Armature Ass'y 115V                   For U.K. set of Armature A'ssy
   023                              1    No                                 1     110V     and Stop Ring E-4 or
         518146-3                           518149-7
         Armature Ass'y 220V                Armature Ass'y 220V                            Self Lock 6
   023                              1    No                                 1
         515193-5                           515218-5
         Armature Ass'y 240V                Armature Ass'y 240V
   023                              1    No                                 1
         515194-3                           515219-3

For GD0810C
Item No.     Current part          Q'ty I/C       New part                 Q'ty                    Note
         Stop Ring E-4                      Self Lock 6
   030                              1    No                                 1
         961011-9                           259039-2
         Armature Ass'y 115V                Armature Ass'y 115V
   023                              1    No                                 1
         515196-9                           515211-9                                       Interchangeable as a
         Armature Ass'y 115V                Armature Ass'y 115V                   For U.K. set of Armature A'ssy
   023                              1    No                                 1
         518147-1                           518148-9                              110V     and Stop Ring E-4 or
         Armature Ass'y 220V                Armature Ass'y 220V                            Self Lock 6
   023                              1    No                                 1
         515198-5                           515213-5
         Armature Ass'y 240V                Armature Ass'y 240V
   023                              1    No                                 1
         515199-3                           515214-3


Implementation
To be informed later
