Image preview - the first page of the document
66600A-WW-1


>> Download 66600A-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject              Change of Armature Assemblies
                                                                                                    66600A


For Models           9560, 9561, 9562, 9563, 9564, 9565

Country              All countries
Description          Armature Assemblies have been changed as shown below.


                        Current                                                    New




                          Groove for Stop Ring                     Groove for Stop Ring has been eliminated.



Interchangeability(I/C)
Item No.        Current part                 Q'ty I/C          New part               Q'ty          Note
           Armature Assembly 115V                       Armature Assembly 115V
    013                                       1   Yes                                   1
           515186-2                                     515246-0
           Armature Assembly 220V                       Armature Assembly 220V
    013                                       1   Yes                                   1    For 9560, 9561, 9562
           515188-8                                     515248-6
           Armature Assembly 240V                       Armature Assembly 240V
    013                                       1   Yes                                   1
           515189-6                                     515249-4
           Armature Assembly 115V                       Armature Assembly 115V
    013                                       1   Yes                                   1
           515176-5                                     515231-3
           Armature Assembly 220V                       Armature Assembly 220V
    013                                       1   Yes                                   1    For 9563, 9564, 9565
           515178-1                                     515233-9
           Armature Assembly 240V                       Armature Assembly 240V
    013                                       1   Yes                                   1
           515179-9                                     515234-7



Implementation
9564: From serial No. 17129E (Sep., 2002)
The remaining models: To be informed later
