Image preview - the first page of the document
66798-WW-1


>> Download 66798-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Battery Charger DC9711
                                                                                                             66798


For Models             6017D, 6018D, 6019D, 6095D, 6096D, 8402VD, DC9711
Country                European countries

Description            Battery Charger DC9711 has been changed by MME.
                       New Battery Charger is interchangeable with Current one, and can be stored in current Plastic
                       Carrying Cases for subject models.
                       Concerning repairing parts, they are not interchangeable.
                       FRIWO mark (below) has been shown on the Name Plate of New Battery Charger for distinction.


                           F W H K



Interchangeability(I/C)
Item No.         Current part               Q'ty I/C          New part                    Q'ty              Note
           Battery Charger DC9711                     Battery Charger DC9711                     For European countries
    F01                                      1    Yes                                      1     except U.K.
           193123-2                                   193123-2
           Battery Charger DC9711                     Battery Charger DC9711
    F02                                      1    Yes 193124-0                             1     For U.K.
           193124-0
    002    Charger Case Set                             Charger Case Set
                                             1    No                                       1
    004    183277-3                                     183550-1
           Battery Box                                  Battery Box
    007                                      1    No                                       1     For European countries
           417163-9                                     418098-7
           Circuit Board                                Circuit Board
    006                                      1    No                                       1
           631399-8                                     631518-6
           Vinyl Cord 0.75-2-2.0                        Vinyl Cord 0.75-2-2.0                    For European countries
    003                                      1    Yes                                      1
           667985-9                                     667822-7                                 except U.K.
           Vinyl Cord 0.75-2-2.0                        Vinyl Cord 0.75-2-2.0
    003                                      1    Yes                                      1     For U.K.
           667986-7                                     667823-5


Note
Battery Charger DC9711 has not been changed by MJ yet.

Implementation
To be informed later
