66726-WW-1


>> Download 66726-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Flange
                                                                                                             66726


For Models           2414B, 2414NB, 2414DB
Country              All countries
Description          Current Outer Flange has been discontinued.
                     Instead, current Inner Flange has been replaced as Outer Flange as illustrated below.


       Current                        New




                         It is also used as Inner Flange.                                    Inner Flange
                                                                                             2414B: Item No.009
                                                                                             2414NB: Item No.018
                                                                                             2414DB: Item No.011
                                                                                             These remain unchanged.

Interchangeability(I/C)
  Item No.           Current part                  Q'ty I/C           New part                   Q'ty         Note
2414B : 004   Outer Flange 90                                 Flange 90                                 All countries
2414NB: 003                                          1                                            1     except Australia,
2414DB: 003   224300-6                                        224299-5                                  New Zealand
2414B : 004   Outer Flange 120                                Flange 120                                For Australia,
                                                     1                                            1
2414NB: 003   224374-7                                        224373-9                                  New Zealand
Interchangeability mark ;
The arrow      means that the new part is substituted for the current.

Implementation
MJ plant
2414B: From serial No.193558E (July 2002) for Australia, New Zealand
2414B: From serial No.193498E (July 2002) for other countries
2414NB: From serial No.3444E (July 2002)
MCC plant
2414DB, 2414NB: From July 2002 production.
MCA plant
2414DB, 2414NB: Already discontinued.
