TECHNICAL INFORMATION
Subject              Change of Pad 150
                                                                                                         66849


For Models           BO6030, BO6040
Country              All countries
Description          Pad 150 has been replaced by Rubber Pad as shown below.




                                Current               New
                Color            Gray                 White




Interchangeability(I/C)

    Item No.     Current part             Q'ty I/C         New part            Q'ty               Note
             Pad 150 (Soft)                           Rubber Pad (Soft)               MA package written in English,
                                            1                                   1
                                                                                      French and Spanish,
 BO6030: 046 193286-4                                 A-91207
 BO6040: 033 Pad 150 (Soft)                           Rubber Pad (Soft)               MJ package written in English,
                                            1                                   1     Dutch, French, German, Italian
             193299-5                                 A-87812
                                                                                      and Spanish.
Interchangeability mark ;
The arrow      means that the new part is substituted for the current.

Note
Replace the current Pad 150 for BO6030 and BO6040 as the replacement part for BO6040 only.

Implementation
BO6030: From August 2002 production
BO6040: As soon as the current part is running out.
