Image preview - the first page of the document
66905-WW-1


>> Download 66905-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject               Change of Gear Housing Complete, Gear Housing Cover Complete
                                                                                                        66905


For Models            DP4700

Country               All countries
Description           Gear Housing Complete and Gear Housing Cover Complete have been modified
                      as illustrated below.

Gear Housing Complete
                       Current                                                      New

                                Radius: 3.0 mm (1/8")                                     Radius: 5.0 mm (3/16")




                                      Thickness:                                               Thickness:
                                      3.0 mm (1/8")                                            5.0 mm (3/16")

                             Radius: 22.0 mm (7/8")                                  Radius: 24.0 mm (15/16")


Gear Housing Cover Complete
                       Current                                                      New




      Thickness:                                                 Thickness:
      3.0 mm (1/8")                                              5.0 mm (3/16")

    Radius: 22.0 mm (7/8")                                     Radius: 24.0 mm (15/16")



Interchangeability(I/C)
Item No.        Current part                  Q'ty I/C           New part                     Q'ty       Note
           Gear Housing Complete                           Gear Housing Complete
    010                                        1      No                                        1
           157010-9                                        153551-3
                                                                                                     Interchangeable
           Gear Housing Cover                              Gear Housing Cover                             as a set
    015    Complete                            1      No   Complete                             1
           157011-7                                        153552-1


Implementation
From serial No.730537E (Aug.,2002)
