Image preview - the first page of the document
66915-WW-1


>> Download 66915-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Field
                                                                                                         66915
                                                                                                      (Page 1 of 4)


For Models             1911B, 1912B

Country                All countries

Description            See below.

For 1911B for European countries, China, Australia, New Zealand, Papua New Guinea
Field without Choke Coil has been replaced by Field with Choke Coil.

                        Current                                                    New
                                                                                             Tube
                                                                               Black

                                                                                              Black
                                                                Orange
                                                                                                Orange



                                                                                             Tube


    Refer to wiring section on page 2 and 3 for color of             Choke Coil
    Lead Wires.


For 1911B for Canada, Panama, Dominica, Chile, Kuwait, Saudi Arabia, Egypt, Hong Kong, Indonesia, Korea,
Malaysia, Philippines, Singapore, Thailand, Vietnam, Tahiti.
For 1912B for U.S.A., Mexico, Panama.
Field has been changed as shown below.

                        Current                                                    New




    Refer to wiring section on page 2 and 3 for color of   Refer to wiring section on page 2 and 3 for color of
    Lead Wires.                                            Lead Wires.
                                                                                                                   66915
                                                                                                                  (Page 2 of 4)



Wiring has been changed as shown below.
For 1911B for China, Australia, New Zealand, Papua New Guinea, European countries

                                             Switch                                   Brush Holder




                         Power Supply Cord
                                             3        2
                                                          White
                                                                      Noise                      Field        Brush Holder
                                                          White       Suppressor
    Current                                  6        5


                                                                               Colored Lead Wires
                                                           For China, European countries except U.K. (110V, 240V): blue
                                                           For Australia, New Zealand, Papua New Guinea, U.K. (240V): red
                                                           For U.K. (110V): sky blue
                                             Switch                                       Choke Coil
                                                                  black
                         Power Supply Cord




                                             3        2                                                  orange
                                                          White       Noise                  Field        Brush Holder
     New                                                  White
                                                                      Suppressor
                                                                                                          (Front side)
                                             6        5                              black
                                                                  orange
                                                                             Brush Holder
                                                                              (Rear side)


For 1911B for Canada, Hong Kong
For 1912B for U.S.A., Mexico, Panama

                                             Switch                                Brush Holder
                         Power Supply Cord




                                             3    2
                                                                                             Field         Brush Holder

    Current                                  6        5



                                                                           Colored Lead Wires
                                                                  For Hong Kong: blue
                                                                  For Canada, U.S.A., Mexico, Panama: sky blue

                                             Switch
                                                                  black
                         Power Supply Cord




                                             3        2
                                                                                             Field        Brush Holder
     New                                                                                                  (Front side)

                                             6        5                             black
                                                                  black
                                                                           Brush Holder
                                                                            (Rear side)
                                                                                                                           66915
                                                                                                                         (Page 3 of 4)


For 1911B for Tahiti

                                                          Switch                           Brush Holder
                                                                           blue




                                 Power Supply Cord
                                                         2         1
                                                                                                   Field           Brush Holder
    Current                                                                                 blue
                                                                                                           blue
                                                         4         3
                                                                           blue



                                                          Switch
                                                                           black
                                 Power Supply Cord




                                                         2         1
                                                                                                   Field          Brush Holder
     New                                                                                                          (Front side)
                                                         4         3                      black
                                                                           orange Brush Holder
                                                                                   (Rear side)


For 1911B for Dominica, Panama, Chile, Egypt, Kuwait, Saudi Arabia (115V, 220V), Indonesia, Korea, Malaysia,
Thailand, Philippines, Singapore, Vietnam

                                                          Switch                           Brush Holder
                            Power Supply Cord




                                                         3         2
                                                                                                   Field          Brush Holder


    Current
                                                         Connector
                                                                     Colored Lead Wires
                       For Chile, Egypt, Saudi Arabia (220V), Indonesia, Korea, Thailand, Philippines, Vietnam: blue
                       For Dominica, Singapore, Malaysia, Kuwait: red
                       For Panama, Saudi Arabia (115V): sky blue

                                                             Switch
                                                                           black
                                     Power Supply Cord




                                                             3         2
                                                                                                   Field          Brush Holder
     New                                                                                                          (Front side)
                                                                                           black
                                                                           orange

                                                             Connector             Brush Holder
                                                                                    (Rear side)
                                                                                                            66915
                                                                                                          (Page 4 of 4)

 Interchangeability(I/C)
For 1911B
 Item No.      Current part               Q'ty I/C         New part           Q'ty                 Note
            Field Assembly 115V                      Field Assembly 115V
   030                                     1                                   1     U.K. (110V) only
            522416-4                                 599023-8
            Field Assembly 115V                      Field Assembly 115V
   030                                     1                                   1 115V countries except U.K.
            522416-4                                 594486-3
            Field Assembly 220V                      Field Assembly 220V             China, European countries
   030                                     1                                   1
            522418-0                                 599024-6                        except U.K.
            Field Assembly 220V                      Field Assembly 220V             220V countries except China
   030                                     1                                   1
            522418-0                                 594488-9                        and Europe
            Field Assembly 240V                      Field Assembly 240V             U.K (240V), Australia,
   030                                     1                                   1     Papua New Guinea,
            522419-8                                 599025-4
                                                                                     New Zealand,
                                                                                     240V countries except Australia,
            Field Assembly 240V                      Field Assembly 240V
   030                                     1                                   1 New Zealand, Papua New Guinea,
            522419-8                                 594489-7                        U.K.(240V)


For 1912B
Item No.       Current part               Q'ty I/C          New part               Q'ty             Note
            Field Assembly 115V                       Field Assembly 115V
   030                                     1                                         1    115V countries except U.K.
            522416-4                                  594486-3
            Power Supply Cord                         Power Supply Cord
   001                                     1    No                                   1
            664424-0                                  660002-4
                                                      Cord Guard
  E02                                                                                1            U.S.A. only.
                                                      682502-4
                                                      Strain Relief                         Interchangeable as a set
  E03                                                                                1
                                                      687063-9
                                                      Pan Head Screw
  E04                                                                                2
                                                      911133-5
Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.


 Implementation
To be informed later
